blow molding machine
Zhiyu Xu
Contact person
Basic Information
MingDa MD55R series full-automatic blow molding machines suitable for making 5ml 5L bottles with all kinds of plastics except PET,multi-layers,view line,etc. The machine equipped with Siemens PLC,Taiwan ABBA linear guider,inverter,position sensor...with optimized hydraulic oil loop design,offers you a stable,safe,high efficiency,energy saving solutions. System ItemUnitBasic parameter Basic Spec Plastic fit for PE PP PVC PAMax hollow product volume L2Diehead amount set1234Size(LxWxH) M3.05x2.17x2.28Weight ton3.4 Clamping System Clamping force kN30Template distance mm120-350Template stroke 230Max template size(WxH) mm340x320Mould thickness mm125-180 Extrusion System Screw Dia mm55Screw L/D ratio L/D24Plasticizing capacity (HDPE) Kg/h35Screw heating zone zone3Screw heating power kW8Screw fans power kW0.42Extrusion motors power kW11 Die head Diehead heating zone zone2Diehead heating power kW4.2Sprue-die dia(max) mm75 Power General power kW34.5Oil-pump motor power kW5.5Air pressure Mpa0.6-0.8Average power kW23.9Compressed air dosage m3min0.4Cooling water dosage L/min50
Delivery terms and packaging
Packaging Detail: fumigation-free pakaging, or fumigated pallets Delivery Detail: 45days
