Full-automatic extrusion blow molding machine(MD45

MingDa MD45R series full-automatic blow molding machines suitable for making 5ml 1L bottles with all kinds of plastics except PET. MingDa blow moldingmachine equipped with Siemens PLC,Taiwan ABBA linear guider,inverter...with optimized hydraulic oil loop design,offers you a stable,safe,high efficiency,energy saving solutions.More details of configurations and technical parameters,pls don't hesitate to contact us. Blow molding machine model MD45Rx3: Screw diameter 45mm,double station,tri-dieheads,centre to center distance 50mm or 60mm,single layer,suitable for making 100ml bottles. System ItemUnitBasic paramters Basic Spec Plastic fit for PE PP PVC PAMax hollow product volume L1Diehead amount set123Size(LxWxH) M2.22x1.94x1.98Weight ton1.8 Clamping System Clamping force kN25Template distance mm110-260Template stroke 150Max template size(WxH) mm250x220Mould thickness mm125-200 Extrusion System Screw Dia mm45Screw L/D ratio L/D24Plasticizing capacity (HDPE) Kg/h25Screw heating zone zone3Screw heating power kW5.5Screw fans power kW0.28Extrusion motors power kW7.5 Die head Diehead heating zone zone2Diehead heating power kW3.5Sprue-die dia(max) mm50 Power General power kW18Oil-pump motor power kW4Air pressure Mpa0.6-0.8Average power kW13.5Compressed air dosage m3min0.4Cooling water dosage L/min35
